SIPLUS S7-1500 CM PTP RS232, part number 6AG2541-1AD00-4AB0, provides a communications module for serial connection RS-232 with 9-pin D-sub plug and specified serial protocols.
Detailed Parameters
Product family:SIPLUS S7-1500 CM PTP RS232
Based on:6ES7541-1AD00-0AB0
Conformal coating:with conformal coating
Operating temperature:-40…+70 °C
OT4 with ST1/2:OT4 with ST1/2 (+85 °C for 10 minutes)
Interface:serial connection RS-232
Connector:9-pin D-sub plug
Protocols/functions:Freeport, 3964 (R), USS, MODBUS RTU master, slave
Data rate:115200 Kbit/s
Engineering Context
SIPLUS S7-1500 CM PTP RS232 provides a communications module for serial connection RS-232.
The module is based on 6ES7541-1AD00-0AB0 and includes conformal coating.
Support is specified for Freeport, 3964 (R), USS, and MODBUS RTU master/slave at 115200 Kbit/s.
FAQ
1. What is the communication interface type for 6AG2541-1AD00-4AB0?
It is a communications module for serial connection RS-232.
2. Which connector is provided on the 6AG2541-1AD00-4AB0 module?
A 9-pin D-sub plug.
3. Which serial protocols are explicitly supported?
Freeport, 3964 (R), USS, and MODBUS RTU master/slave.
4. What is the specified data rate for the serial connection?
115200 Kbit/s.
5. What operating temperature range is specified for the module?
-40…+70 °C.
